Current Location>>Products>>10G Transcivers

10G Transcivers

Egone 10G series optical modules include 10G SFP+ SR、10G SFP+ LR、10G SFP+ ER、10G SFP+ ZR、10G SFP+ CWDM、10G SFP+ DWDM；10G XFP SR、10G XFP LR、10G XFP ER、10G XFP ZR、10G XFP CWDM、10G XFP DWDM、and other products. An optical module providing commercial temperature, extended temperature, and industrial temperature is selected for use by customers. The product uses the MPO or LC interface, compatible with IEEE802.3ae and SFF-8472 standards, with low power consumption, small volume, high rate. It is mainly used in data center interconnection, SONET/SDH, metropolitan area network, 4G LET wireless network, transmission network, high-speed peer to peer connection, optical fiber channel and so on.10G Optical modules can be adapted to HUAWEI、H3C、CISCO、Alcatel-lucent、Juniper and other devices.

BUY

P/N	Product Description	Date Rate	Reach	Wavelength	Transmitter	Receiver	Power Consumption	Temperature (deg C)	Date Sheet
HXXD-ALxx41I	100GHz DWDM XFP	10Gb/s	40km	CH17~CH61	EML	PIN	<3.5W	-40~+85°C
HXXD-ALxx41C	100GHz DWDM XFP	10Gb/s	40km	CH17~CH61	EML	PIN	<3.5W	0~+70°C
HXXD-ALxx81I	100GHz DWDM XFP	10Gb/s	80km	CH17~CH61	EML	APD	<3.5W	-40~+85°C
HXXD-ALxx81C	100GHz DWDM XFP	10Gb/s	80km	CH17~CH61	EML	APD	<3.5W	0~+70°C
HXXC-ALx41I	XFP CWDM	10Gb/s	40km	1470~1610	EML	PIN	<3.5W	-40~+85°C
HXXC-ALx41C	XFP CWDM	10Gb/s	40km	1470~1610	EML	PIN	<3.5W	0~+70°C
HXXC-ALx81I	XFP CWDM	10Gb/s	80km	1470~1610	EML	APD	<3.5W	-40~+85°C
HXXC-ALx81C	XFP CWDM	10Gb/s	80km	1470~1610	EML	APD	<3.5W	0~+70°C
HXXX-AL1N2I	XFP SR	10Gb/s	300m	850nm	VCSEL	PIN	<2.0W	-40~+85°C
HXXX-AL1N2C	XFP SR	10Gb/s	300m	850nm	VCSEL	PIN	<2.0W	0~+70°C
HXXX-AL3Q1I	XFP IR	10Gb/s	2km	1310nm	FP	PIN	<2.0W	-40~+85°C
HXXX-AL3Q1C	XFP IR	10Gb/s	2km	1310nm	FP	PIN	<2.0W	0~+70°C
HXXX-AL311I	XFP LR	10Gb/s	10km	1310km	DFB	PIN	<2.0W	-40~+85°C
HXXX-AL311C	XFP LR	10Gb/s	10km	1310nm	DFB	PIN	<2.0W	0~+70°C
HXSX-AL8613C	SFP+ BIDI	10Gb/s	10km	1330nm	DFB	PIN	<1.5W	0~+70°C
HXSX-AL6813C	SFP+ BIDI	10Gb/s	10km	1270nm	DFB	PIN	<1.5W	0~+70°C
HXXX-AL541I	XFP ER	10Gb/s	40km	1550nm	EML	PIN	<3.5W	-40~+85°C
HXSX-AL8643C	SFP+ BIDI	10Gb/s	40km	1330nm	EML	PIN	<1.5W	0~+70°C
HXSX-AL6843C	SFP+ BIDI	10Gb/s	40km	1270nm	DFB	PIN	<1.5W	0~+70°C
HXXX-AL541C	XFP ER	10Gb/s	40km	1550nm	EML	PIN	<3.5W	0~+70°C
HXXX-AL581I	XFP ZR	10Gb/s	80km	1550nm	EML	APD	<3.5W	-40~+85°C
